COLOUR
Gloss Silver with UD Carbon
CASSETTE
SRAM XS 1275, T-Type, 10-52
FRAME
Uni-directional carbon mainframe and seatstays, Tapered Head tube, ISCG 2 Guide mounts, Internal cable routing, Shape.it Link V2 and 12,mm x 148mm Boost dropouts
CHAIN
SRAM GX T-Type, 12 Speed
FORK
RockShox Lyrik Select+ 29”, 150mm Travel, 44mm Offset, DebonAir+, Charger 3 RC2 Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost
CRANKSET
Whyte 155mm ISIS arms, GX Gen4 Direct Mount 36T, T-Type
REAR SHOCK
RockShox Deluxe Select + RT, DebonAir, Fast Black Coating, Adjustable Rebound and 2 Position Compression
BOTTOM BRACKET
N/A
HEADSET
FSA No.69/SRS 1-1/8”/1.5” ACB - W/15mm top cover - side entry internal routing
SEATPOST
Whyte drop.it II Adjust, 30.9mm, M/L 140-170mm Travel, XL 170-200mm Travel, MMX Paddle Remote Lever
REAR HUB
Alloy, Light assist e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole
SADDLE
Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail
FRONT HUB
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 28 Hole
HANDLEBAR
Whyte Custom 6061 Alloy, 20mm Rise, 35mm Bar Bore, 800mm Wide
SPOKES
DT Swiss New Champion 2.0mm, Black Stainless, Brass Nipples
STEM
Whyte Trail Full CNC, 32mm Extension, 35 Barbore
RIMS
Whyte Innegra Infused carbon Trail rims, 28H front, 32H rear
GRIPS
Whyte Lock-on Enduro Grip
TYRE
Maxxis Minion DHF, Exo TR MaxxGripp 29x2.5 Front, Maxxis Dissector, Exo+ TR MaxxTerra 29x2.4 rear
BRAKES FRONT
SRAM Code Bronze Stealth, 4 Piston, 200mmDisc
SHIFT LEVERS
SRAM AXS Pod, Right, MMX
BRAKES REAR
SRAM Code Bronze Stealth, 4 Piston, 200mmDisc
FRONT MECH
N/A
BRAKE LEVERS
SRAM Code Bronze Stealth
REAR MECH
SRAM GX T-Type AXS
PEDALS
Fibre Reinforced Composite Platform
WEIGHT
TBC
